PSR3584, V-Band, Gen3, Dual Ball Bearing
Artnr: 102135513=112135219+194335218
Stock Status: External warehouse, approx. 1-1.5 week delivery
The product is in an external warehouse where the stock status may be uncertain.
Description
Exhaust housing with V-Band Flanges and AR 0.83.
GT35 Sized turbo
Dual ball bearing
10 Blade billet compressor wheel with "Extended Tapered Tip Technology"
10 Bladed turbine wheel in Inconel 713c, larger and designed for high power outputs
Socket for speed sensor
Rated for up to 1000HP
V-Band's flange for outlet is included
Compared to original Garrett GTX3584 G2 in dyno on RB26. 812Whp with the Garrett, 858Whp with the Pulsar, at the same boost pressure. See pic.
Compressor wheel: 67*84mm
Turbine wheel: 74*66mm
Inlet compressor: 4"
Outlet compressor: 2"
Exhaust housing inlet: T3
Exhaust housing outlet: 3" V-Band
Oil supply: AN4 with restrictor
Oil return: Standard T3 Oil return
Water In/Out: M14x1.5
