DLS Performance PE10.D2, 10 tums bas

The DLS PE10.D2 is a 10 inch woofer that offers an exceptional sound experience at a very affordable price! The woofer is the result of carefully selected materials and advanced technology to deliver outstanding performance in this price range. Every part is optimized and balanced to achieve really nice measurements and Thiele/Small parameters.

300W RMS / 600W MAX

20-300 Hz

2x2 Ohm

2" Kapton voice coils with 4-layer copper wire

86 dB sensitivity

Durable steel basket

Especially suitable for smaller closed boxes

A bass that delivers on all fronts

Every small detail of the PE10.D2 is carefully crafted to give the sound a wonderful push in the right direction. The treated NPP (Non-Pressed Paper) cone, which is the very heart of this bass element, is not only robust but also designed to deliver every nuance with high precision and clarity. The ferrite motor drives at the same time, resulting in a powerful bass with good musicality and great responsiveness. The back plate of The woofer gives the voice coil good opportunities to move further in the magnet gap, which results in a longer throw. For those with sharp eyes, the design, especially the cone, is reminiscent of the early (and somewhat legendary) DLS product design. A true joy to both look at and listen to.

Perfect in the slightly smaller box

The element is especially tailored for small closed boxes. A closed box will give the element clean and authentic bass. A compact box can easily disappear behind side panels, under the cargo floor, in the spare wheel well, under the glove compartment as a front sub or why not in a truck cab? These are just a few examples of placement options with a compact box. DLS recommends a closed box that is around 12-20 liters in size.

Specifications

Fs: 29 Hz

Re: 3.8 (1.9+1.9) Ohm

Qms: 6.42

Qes: 0.50

Qts: 0.47

Cms: 0.23 mm/N

Mms: 98.4g

Bl: 12.9

Vase: 45L

SD: 359.7 cm²

Xmax: ±9mm

CEO: 1.5 L
