DLS Reference RCW12.D2, well-playing 12 inch bass

DLS RCW12.D2, an impressive 12-inch subwoofer with amazing sound and performance. The legendary company DLS has taken a look at its older woofers and created something completely new. In the catalog you will find a couple of absolutely incredible woofers, but have recast them in a new form. The Reference series woofers are absolutely outstanding, and the RCW12.D2 is no exception.

600W RMS / 1200 MAX

2x2 Ohm

Aluminum cone

Double-stacked 52oz ferrite magnet

88 dB sensitivity

Frequency range: 20-500 Hz

Offers hard-to-beat bass

Heavy-duty pressure terminals

DLS has done it again

A woofer is designed to deliver a musical, responsive and deep bass. A bass that is guaranteed to satisfy even the most discerning enthusiast. DLS are very skilled at designing high-quality sound and the RCW12.D2 delivers jaw-dropping bass that will impress anyone who gets the chance to experience it.

A well-chosen ported box will bring out the very best from the driver. The manual that comes in the box contains three different suggestions for box types: ported (SPL), ported or ported (for extra deep bass).

Quality bass

Good bass places high demands on the choice of materials and incredible knowledge when it comes to the manufacturing itself. It shows, as the bass driver is manufactured with the greatest possible precision. With a stylish black anodized aluminum cone and double-stacked premium ferrite magnet motors in perfect harmony, it leads to a bass that has the ability to hit surprisingly hard.

The short-circuit ring, also made of aluminum, reduces inductance and distortion. This results in a detailed bass, even when you crawl down into the frequencies, which with great finesse captures every nuance in your favorite music.

A classic design

DLS has given the element two 2 Ohm voice coils on a non-magnetic TIL shaper, which ensures fantastic musicality and the ability to adjust the impedance to taste and liking. Do you recognize the classic DLS basket? The basket is stylish and, to say the least, sturdy, but also ensures optimal ventilation, so you will be able to take the RCW12D.D2 with you to your next sound build. And several buildings after that...

Specifications

Fs: 25 Hz

Re: 3.8 (1.9+1.9) Ohm

Qms: 4.29

Qes: 0.34

Qts: 0.31

Cms: 0.22 mm/N

Mms: 176.6g

Bl: 16.4

Vase: 80.3L

SD: 510 cm²

Xmax: ±11mm

CEO: 1.6 L
