PSR3584 Gen2, Ball Bearing, 1000HP
Artnr: 102135236=112135201+194335211
Stock Status: External warehouse, approx. 1-1.5 week delivery
The product is in an external warehouse where the stock status may be uncertain.
Description
Exhaust housing with V-Band flanges and AR 1.01.
GT35 Sized Turbo
Dual ball bearing
9 Blade Gen2 billet compressor wheel with "Extended Tip Technology"
9 Blade turbine wheel in Inconel 713c
Socket for speed sensor
Rated for up to 1000Hp
Compressor wheel: 67*84m
Turbine wheel: 68*62mm
Inlet compressor: 4"
Outlet compressor: 2.5"
Exhaust manifold inlet: 2.5" V-Band
Outlet Exhaust: 3" V-Band
Oil supply: AN4 with restrictor
Oil return: Standard T3 Return Flange
Water In/Out: M14x1.5
