Description
Super -glued and stylish Refinity Aries with adequate light prints!
For those of you who would like to have a ramp that does not take up so much space in the front, or want a smaller ramp recessed in the lower grill!
The basic price applies to cars that do not need to have canbus module!
Of course, we can also mount this package on a car that requires Canbus and add appropriate control for this.
Read more about the ramp here: Link Contact us by phone, mail, or the contact form here on the page to book a mounting!
Note that all our mounting packages can be combined with different types of controls, and may also need to change slightly in component version depending on how the car in question is designed.
This can then mean some price differences between different car models.
Technical Data
| Varumärke | Refinity |
| Lyser med 1 lux på | 800 meter |
| Faktiska lumen | 10428 |
| Teoretiska lumen | 22080 |
| Spänning | 10-32V |
| Effekt | 240W |
| Ström | 12V/19,05A, 24V/8,57A |
| EMC klass | R10 |
| E-godkänd | R148, R149 |
| Mått (LxHxB) | 577 x 63,5 x 64 mm |
| Garantitid | 5 år |
| Färgtemperatur | 5700 K |
| Anslutning | Kort kabel med 3-polig DT-kontakt |
| Skyddsklass | IP67 |
| Husmaterial | Aluminium |
| Ljuskälla | LED |
| Antal dioder | 24st |
| LED effekt | 10W |
| Vikt (kg) | 2.7 |
