Turbo GT35-6162 A/R 0.82 - Ball Bearing Billet Comp Wheel
GT35 Trimnings turbo med kullager och billet kompressor hjul, i övrigt samma spec som den glidlagrade GT35'anGT6162
Description
New model 2021-07-30 with V-band on the exhaust housing!
This model also has a larger AR on the exhaust housing and is suitable for engines with a little more cylinder volume. 2.8L and larger.
Output 450hp-620hp.
Flange in turbine: T3
Flange out turbine: V-band 90mm for welding to 76mm pipe (Choose if you want it in the scroll bar)
Hose connection compressor in 100mm
Hose connection compressor out 64mm
Water cooling. Connection M18x1.5mm.
Buy connection: Click here or in the scroll bar
We recommend that you connect the water cooling. And that the oil restrictor that is included is used.
Oil in. Thread M12x1.25mm, or flange with bolt spacing 38mm
Oil out. Bolt pitch 51mm
For separate wastegate.
COMPRESSOR trim 48 exd 81.7mm ind 61mm A/R 0.70
TURBINE trim 55 ind 67.8mm exd 62mm A/R 0.82
10-blade high-flow turbine provides large flow on a small diameter for less inertia and faster response.
We also have loose flanges and gaskets for the unit if you build it yourself.
This is included:
T3 Gasket
Banjo bolt
Oil restrictor
As well as 2 gaskets for oil in and out
